Description

Fits

Year	Make	Model	Part Number
1994-1999	Ram	1500/2500/3500	8565-02
2000-2001	Dodge	1500	8565-02
2000-2009	Ram	2500/3500	8565-02
2006-2008	Dodge	1500	8565-02
2010-2013	Ram	2500/3500	8565-03
2000-2001	Dodge Ram	1500	8565-04
2000-2001	Dodge Ram	2500/3500 (Some models only)	8565-04

Synergy Stepped 16mm Cam Bolt Eliminator Kit for Dodge Trucks is designed specifically for use with front lower control arms featuring stock-style Clevite bushings. This kit takes the place of the stock cam bolts, removing all adjustability at the axle while increasing strength.

The stepped design provides a smooth surface for evenly clamping the control arm bushing, GREATLY extending bushing life, and locates the cam bolt eliminator inside the alignment groove for maximum strength.

Part Number: 8565-02

Features

• Made from 303 Stainless Steel
• Provides smooth mounting surface for bushing face
• Eliminates factory alignment cam washers
• Retains factory control arm bolt
• Caster correction
• Allows for even torque to be applied on bushing surface
• Includes 4 cam bolt eliminators for both front lower control arms

Additional Info:

• 8565-02
  • Bolt Size: 16MM
  • Cam Length: 1.400"
  • Outer Diameter: 1.980"
• 8565-03

  • Bolt Size: 18MM
  • Cam Length: 1.456"
  • Outer Diameter: 2.000"

Installation

• Click Here

Notes

• These are required for use with Synergy control arms using Dual Durometer Bushings (DDB) when eliminating the stock cam bolts
• 1994-1999 1500 4x4 2500 / 3500 *Requires 9/16'' hole to be drilled in mount
• 2013 Dodge Ram 3500's were a split year for production. If your truck has radius arms use Dodge Ram 2014+ pages
